***ALERT***
There have been some reports that the intake boot between the air filter box and the throttle body are pulling off the throttle body and allowing dirt/dust to be sucked right into the engine causing a need for a top end engine rebuild. These reports also state that the boot seems to be too short to adequately mount to the throttle body and pulling off. A recent finding shows why some are having this problem and others are not.
Here's some pics from rzrguy from PRC showing the right and wrong way on how it should be mounted....
- Incorrectly mounted
- Airboxmountbefore.jpg (85.5 KB) Viewed 394 times
- Incorrectly mounted
- Airboxmountbefore2.jpg (63.59 KB) Viewed 392 times
- Correctly mounted
- Airboxmountafter.jpg (74.89 KB) Viewed 391 times
- Service manual pic showing correct mounting found on page 3.19
Original thread from PRC...
http://www.prcforum.com/topic.asp?TOPIC_ID=12536
)
